規格：
材質：鋁合金
應用：産品廣泛應用于航空、國家電網線路改造、交通運輸等領域
咨詢熱線：
元旺電工：0543-8197887
創輝新材料：0543-6981710
返回列表産品廣泛應用于航空、國家電網線路改造、交通運輸、工業産品、電子産品、建築建材、電力電纜、架空線和家用電器等領域。
| 規格型号 | 牌号 Type | 狀态 Temper | 抗拉強度 Tensile strength (Mpa) | 伸長率 Elongation (%,min) | 電阻率 Resistivity (nΩ•m, max) | 導電率 Conductivity (%IACS, min) |
| 電工圓鋁杆 Aluminum rod for Electrical purpose |
1A60 1R50 | O | 60-90 | 25 | 27.55 | 62.58 |
| H12 | 80-110 | 13 | 27.85 | 61.91 | ||
| H13 | 95-115 | 11 | 28.01 | 61.55 | ||
| H14 | 110-130 | 8 | 28.01 | 61.55 | ||
| H16 | 120-150 | 6 | 28.01 | 61.55 | ||
| 1350 | O | 60-95 | 25 | 27.9 | 61.80 | |
| H12 | 85-115 | 12 | 28.03 | 61.50 | ||
| H14 | 105-135 | 10 | 28.08 | 61.40 | ||
| H16 | 120-150 | 8 | 28.12 | 61.30 | ||
| 1370 | O | 60-95 | 25 | 27.9 | 61.80 | |
| H12 | 85-115 | 11 | 28.01 | 61.55 | ||
| H13 | 105-135 | 8 | 28.03 | 61.50 | ||
| H14 | 115-150 | 6 | 28.05 | 61.47 | ||
| H16 | 130-160 | 5 | 28.08 | 61.40 | ||
| 6101 | T4 | 150-200 | 10 | 34.5 | 49.97 | |
| 6201 | T4 | 160-220 | 10 | 34.5 | 49.97 | |
| 8030 | H14 | 105-155 | 10 | 29.73 | 57.99 | |
| 擠壓電工圓鋁杆 Aluminum rod for squeezing purpose |
A1070 | - | 100-120 | 15 | - | - |
| A1100 | - | 100-120 | 15 | - | - | |
| A3102 | - | 100-130 | 12 | - | - | |
| A1100 | - | 110-140 | 12 | - | - | |
| 耐熱鋁合金杆 Thermal-resistant Aluminum rod |
8A07 | H15 | 95-135 | 7 | 28.64 | 60.2 |
| H17 | 120-160 | 6 | 31.25 | 55.17 | ||
| NR | LH1(AT1) | 110-130 | 8 | 28.735 | 60 | |
| LH2(AT2) | 165-175 | 6 | 31.347 | 55 | ||
| LH3(AT3) | 165-175 | 6 | 28.735 | 60 | ||
| LH4(AT4) | 165-175 | 6 | 29.726 | 58 | ||
| 高導電工圓鋁杆 Aluminum rod of High Electric Conductivity |
62.5 | A4 | 100-110 | 11 | 27.3373 | 62.5 |
| A6 | 110-130 | 8 | 27.3376 | 62.5 | ||
| A8 | 120～150 | 6 | 27.3376 | 62.5 | ||
| 63 | A4 | 100-110 | 11 | 27.12 | 63 | |
| A6 | 110-130 | 8 | 27.12 | 63 | ||
| A8 | 120～150 | 6 | 27.12 | 63 |
